9.2" widescreen plastic TFT LCD Display;
Resolution: 800*480pixel;
Brightness: 400 nits;
Contrast ratio: 300:1;
Viewing angles: 170°/140°
Screen brand: SHARP
Mirror function: UP and DOWN, LEFT and RIGHT flipped
Interface: VGA/AV input RCA output
Optional: BNC/HDMI/TV
Language: Chinese, English, Italian, Spanish, German, French, Japanese, Korean
Certification: FCC, CE, ROHS, CCC
Display Parameters |
|||||
| Aspect Ratio |
16:9 |
Contrast Ratio | 300:1 | Response Time | 25ms |
| Display Area | 200.4*120.2mm | Brightness | 400 nits | Backlight | CCFL |
| Resolution | 800×480 | Viewing Angle | 170°/140° |
|
|
| Screen Color | 262K | Panel Type | LCD | ||
Specification |
|||||
| Installation | Custom Stand | Frame color | Black | Product Dimensions | 244*172*37mm |
| Power input/output | 110V to 240V input, 12V output | Operating temperature | 0~75℃ | Humidity temperature | 0~85%@40℃ ( non-condensing ) |
| Storage temperature | -25~75℃ | Box Packing Dimensions | 365*225*75mm | ||
